Film Production Machine (Three Layers) - Taiwanese Production
Film Production Machine (Three Layers) - Taiwanese Production
| Model | MSFF1 | MSFF2 | MSFF3 | MSFF4 |
| Screw diameter | 45/50/45 | 50 /55/50 | 60/65/60 | 65 /70/65 |
| Screw rate | 30:01:00 | 30:01:00 | 30：1 | 30:01:00 |
| screw speed | 110 | 110 | 110 | 110 |
| Main engine power | 11/15/2011 | 15/18.5/15 | 22/30/22 | 30/37/30 |
| Head range(mm) | ¢200 | ¢300 | ¢450 | ¢650 |
| Single-sided film thickness (mm) | 0.015-0.15 | 0.02-0.15 | 0.03-0.20 | 0.05-0.20 |
| Maximum width of folded film (mm) | 1000 | 1200 | 1800 | 2500 |
| Maximum productivity | 130kg/h | 150kg/h | 180kg/h | 250kg/h |
| Total electrical capacity (KW) | 85 | 95 | 120 | 180 |
| Machine weight (kg) | 5500 | 6500 | 7500 | 9800 |
| Dimensions (m) | 6.6*2.8*5.5 | 6.8*3*6 | 7*3.2*8.5 | 8.5*5*10.5 |
